SKT1000/26EL2
$218.30
Sin impuestos
SKT1000/26EL2
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Line THYRISTOR
- Hermetic metal cases with ceramic insulators
- Capsule package for double sided cooling
- Shallow design with single sided cooling
- International stu00c3u00a1ndar cases
- Off-state and reverse voltages up to 2800 V
- Amplifying gate
Aplications
- Applications
- DC motor control (e. g. for
- machine tools)
- Controlled rectifiers (e. g.
- For battery charging)
- AC controllers (e. g. for
- temperature control)
- Recommended snubber network e. g. for VRMS < 400 V : R = 33 Ohms/32W, C = 1 uF
Semikron Phase Control SCRs, SKT1000 Series
Semikron
SKT1000/26EL2
SCR, TO-200AD, 2600V, 1000A ; Package Style; TO-200AD
Vrrm (volts); 2600 Volts
Vdrm (volts); 2600 Volts
It (rms) Amps; 2300 Amps
It (avg) Amps; 1000 Amps
Itsm Amps; 19000 Amps
di/dt (A/microseconds); 125
dv/dt (V/microseconds); 1000
I2T@50Hz (A2Sec); 1800000
Vtm (volts); 2 Volts
tq (microseconds); 250 MicroSeconds
Irrm Peak (mA); 100 MilliAmps
Idrm Peak (mA); 100 MilliAmps
Igt (mA); 250 MilliAmps
Vgt (volts); 3 Volts
Puck Size (h x dia.) in.; 1x3
Junction Temp.; 257 Degrees F
Mounting Force; 22~25 kN
RoHS; Yes
Diag. No.; SEKG_SCR_DIAG_B14
SKT1000/26EL2
Referencias Específicas
- Nº Pieza fabricante (NPM)
- SKT1000/26EL2
