- Agotado
SKM400GA173D
$150.94
Sin impuestos
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- IGBT MODULE
- MOS input (voltage controlled)
- N Channel, Homogeneous Si
- Low inductance case
- Very low tail current with low temperature dependence
- High short circuit capability, self limiting to 6 x Icnom
- Latch-up free
- Fast & soft inverse CAL diodes
- Isolated copper Bonding Technology
- Large clearance (13 mm) and creepage distances (20 mm)
Aplications
- Applications
- AC inverter drives on mains 575 - 750 V AC
- DC bus voltage 750 - 1200 V DC
- Public transport
- Switching (not for linear use)
- iliary syst.)
- Switching (not for linear use)
Semikron IGBTs
Semikron
SKM400GA173D
IGBT 400A 1700V SINGLE ; Type; Single
Vces; 1700 Volts DC
Ic; 300 Amps
Vges +/-; 20
Ices Max; 0.3 MilliAmps
Vge(th) Min/Max; 4.8~6.2 Volts
Vce(sat) Max; 3.9 Volts
Height (mm); 36.5
Width (mm); 106.4
Depth (mm); 61.4
Circuit Type; Single IGBT
RoHS; Yes ;
SKM400GA173D
Referencias Específicas
- Nº Pieza fabricante (NPM)
- SKM400GA173D
