- Agotado
PM100RSE060
$206.06
Sin impuestos
PM100RSE060
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- a ) Adopting new 4th generation planar IGBT chip, which
- performance is improved by 1 um fine rule process
- For example, typical VCE(sat)=1.7V
- b ) Using new Diode which is designed to get soft reverse
- recovery characteristics
- c ) Keeping the package compatibility
- The layout/position of both terminal pin and mounting hole
- is same as S-series 3rd generation IPM
- 3 o/ 100A, 600V Current-sense IGBT for 15kHz switching
- 30A, 600V Current-sense regenerative brake IGBT
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for over-current, short-circuit , over-temperature & under-voltage
- Acoustic noise-less 11kW class inverter application
Aplications
- Applications
- General purpose inverter
- servo drives
- motor control
PM100RSE060
Referencias Específicas
- Nº Pieza fabricante (NPM)
- PM100RSE060
