CR2LS-30

26,25 $
Nessuna tassa

VARIOS

PDF CR2LS-30

Características Eléctricas: 30A/400VAC/1U

Marca: No identificado

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

FeaturesAplicaciones
  • Super Rapid Fuses
  • 150-1500 volts AC
  • 10-4700 Amps
  • Features
  • The total clearing I2t is small and the semiconductor circuit
  • is completely protected
  • Since the peak arc voltage at the time of interruption is low
  • damage to other equipment does not occur
  • High interrupting capacity of 200kA of 1000V AC

Marca:

No identificado

Características electricas: 30A/400VAC/1U

Fuji Japanese Fuses, CR Series

Type : FUSE, 30A, 250VAC, SEMI, FOOTED I2T = 350, 100kAIC, 56mm OAL, 42mm C-C, 17.5mm DIA
Amps 30
Volts AC 250
Volts DC 400
Characteristic Semiconductor
Package Type Offset Bolted
Interrupt Rating 100kA @ 250V
I2t Clearing Amps 350 Amps
Length (mm) 56 MilliMeters
Depth (mm) 18.5 MilliMeters
Mounting Centers (mm) 42 MilliMeters
Contáctanos para mas información sobre este u otros productos
ventas@ims-refacciones-industriales.com
CR2LS-30

Riferimenti Specifici

MPN
CR2LS-30
