SKR71/12
13,86 $
Nessuna tassa
SKR71/12
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Rectifier Diode
- Reverse voltage up to 1600 V
- Hermetic metal cases with glass insulators
- Threaded studs ISO M8(SKN/R 71 also 1/4-
- 28UNF)
- SKN : anode to stud
- SKR : cathode to stud
Aplications
- Applications
- All-purpose mean power rectifier
- diodes
- Cooling via heatsinks
- Non-controllable and
- half-controllable rectifiers
- Free-wheeling diodes
Semikron Standard Recovery Diodes, SKN70 Series
Semikron
SKR71/12
DIODE, M8, 1200V, 70A, FWD, STD, M8X1.25 ; Package Type; DO-203AB (DO-5)
Polarity; Cathode Stud (Forward)
Vrrm (volts); 1200 Volts
IF (rms) Amps; 150 Amps
IF (avg) Amps; 95 Amps
Ifsm Amps; 1150 Amps
I2T@60Hz (A2Sec); 6600
I2T@50Hz (A2Sec); 6600
Vfm (volts); 1.5 Volts
Junction Temp.; 356 Degrees F
Mounting Force; 35.40 lbf-in
Stud Size; M8 x 1.25
Lead Type; Lug ;
SKR71/12
Riferimenti Specifici
- MPN
- SKR71/12
