SKR2F17/04

3,81 $
Nessuna tassa

MODULOS IGBT

Última actualización

DatasheetSKR2F17/04

26A/400V/1U

No identificado

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Fast Recovery Rectifier Diode
  • Small recovered charge
  • Soft recovery
  • Up to 1000 V reverse voltage
  • Hermetic metal case with glass iinsulator
  • Theaded stud ISO M5 or 10-32 UNF
  • SKN ; anode to stud
  • SKR ; cathode to stud

Aplications

  • Applications
  • Inverse diode for power transistor, GTO thyristor asymmetric thyristor
  • SMPS, inverters, choppers
  • for severe ambient conditions

Semikron Fast Recovery Diodes, SKNR2F17 Series

Semikron

SKR2F17/04

DIODE, M5, 400V, 17A, FWD, 150nS M5X0.80 ; Package Type; DO-203AA (DO-4)

Polarity; Cathode Stud (Forward)

Vrrm (volts); 400 Volts

IF (avg) Amps; 17 Amps

Ifsm Amps; 450 Amps

I2T@60Hz (A2Sec); 1000

I2T@50Hz (A2Sec); 720

Vfm (volts); 2.15 Volts

trr (nanoseconds); 440 NanoSeconds

Junction Temp.; -40~302 Degrees F

Mounting Force; 13.3 lbf-inches

Stud Size; M5 x 0.80

Lead Type; Lug

Lead Length FMS (inches); 0.7283 Inches ;

SKR2F17/04

Riferimenti Specifici

MPN
SKR2F17/04
