SKR141F15

27,72 $
Nessuna tassa

VARIOS

Última actualización

DatasheetSKR141F15

140A/1500V/1U

No identificado

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Fast Recovery Rectifier Diode
  • Small recovered charge
  • Soft recovery
  • Hermetic metal case with glass insulator
  • Threaded stud M 12
  • SKN : anode to stud
  • SKR : cathode to stud

Aplications

  • Applications
  • Inverse diode for GTO and
  • asymmetric thyristor
  • Inverters and choppers
  • A.C. motor control
  • Uniterruptible power supplies
  • (UPS)

Semikron Fast Recovery Diodes, SKNR141F Series

Semikron

SKR141F15

DIODE, M12, 1500V, 140A, FWD, 800nS M12X1.75, SOLDER LUG ; Package Type; DO-205AC (DO-30)

Polarity; Cathode Stud (Forward)

Vrrm (volts); 1500 Volts

IF (avg) Amps; 140 Amps

Ifsm Amps; 2500 Amps

I2T@60Hz (A2Sec); 31000

I2T@50Hz (A2Sec); 22000

Vfm (volts); 1.8 Volts

trr (nanoseconds); 2000 NanoSeconds

Junction Temp.; -40~302 Degrees F

Mounting Force; 88.51 lbf-inches

Stud Size; M12 x 1.50

Lead Type; Lug

Lead Length FMS (inches); 1.85 Inches ;

SKR141F15

Riferimenti Specifici

MPN
SKR141F15
