skn71-04
search
  • skn71-04

SKN71/04

13,86 $
Nessuna tassa

MODULOS IGBT

Última actualización

DatasheetSKN71/04

70A/400V/1U

No identificado

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Rectifier Diode
  • Reverse voltage up to 1600 V
  • Hermetic metal cases with glass insulators
  • Threaded studs ISO M8(SKN/R 71 also 1/4-
  • 28UNF)
  • SKN : anode to stud
  • SKR : cathode to stud

Aplications

  • Applications
  • All-purpose mean power rectifier
  • diodes
  • Cooling via heatsinks
  • Non-controllable and
  • half-controllable rectifiers
  • Free-wheeling diodes

Semikron Standard Recovery Diodes, SKN70 Series

Semikron

SKN71/04

DIODE, M8, 400V, 70A, REV, STD, M8X1.25 ; Package Type; DO-203AB (DO-5)

Polarity; Anode Stud (Reverse)

Vrrm (volts); 400 Volts

IF (rms) Amps; 150 Amps

IF (avg) Amps; 70 Amps

Ifsm Amps; 1150 Amps

I2T@60Hz (A2Sec); 6600

I2T@50Hz (A2Sec); 6600

Vfm (volts); 1.5 Volts

Junction Temp.; 356 Degrees F

Mounting Force; 35.4 lbf-in

Stud Size; M8 x 1.25

Lead Type; Lug ;

SKN71/04

Riferimenti Specifici

MPN
SKN71/04
