SKN26/12

5,54 $
Nessuna tassa

Última actualización

DatasheetSKN26/12

25A/1200V/1U

No identificado

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Rectifier Diode
  • Reverse voltage up to 1600 V
  • Hermetic metal cases with glass insulators
  • Threaded studs ISO M8(SKN/R 71 also 1/4- 28UNF)
  • SKN : anode to stud
  • SKR : cathode to stud

Aplications

  • Applications
  • All-purpose mean power rectifier diodes
  • Cooling via metal plates or heatsinks
  • Non-controllable and half-controllable rectifiers
  • Free-wheeling diodes

Semikron Standard Recovery Diodes, SKN26 Series

Semikron

SKN26/12

DIODE, M6, 1200V, 20A, REV, STD, M6X1.00 ; Package Type; DO-203AA (DO-4)

Polarity; Anode Stud (Reverse)

Vrrm (volts); 1200 Volts

IF (rms) Amps; 40 Amps

IF (avg) Amps; 25 Amps

Ifsm Amps; 375 Amps

I2T@60Hz (A2Sec); 700

I2T@50Hz (A2Sec); 700

Vfm (volts); 1.55 Volts

Junction Temp.; 356 Degrees F

Mounting Force; 17.70 lbf-in

Stud Size; M6 x 1.00

Lead Type; Lug ;

SKN26/12

Riferimenti Specifici

MPN
SKN26/12
