R6012030XXYA
83,16 $
Nessuna tassa
R6012030XXYA
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- General Purpose Rectifier
- Stu00c3u00a1ndar and Reverse Terminals Available
- Flag Lead and Stud Top Terminals Available
- High Surge Current Ratings
- High Rated Blocking Voltages
- Special Electrical Selection forParallel and Series Operation
- Glazed Ceramic Seal Gives High Voltage Creepage and Strike Paths
- Compression Bonded Encapsulation
- JAN Types Available
Aplications
- Applications
- Weldres
- Battery Charges
- Electromechanical Refining
- Metal Reduction
- General Industrial High Current Rectification
Powerex Standard Recovery Diodes, R601 Series
Powerex
R6012030XXYA
DIODE, DO-9, 2000V, 300A, REV ; Package Type; DO-205AB (DO-9)
Polarity; Anode Stud (Reverse)
Vrrm (volts); 2000 Volts
IF (rms) Amps; 470 Amps
IF (avg) Amps; 300 Amps
Ifsm Amps; 6500 Amps
I2T@60Hz (A2Sec); 175000
Vfm (volts); 1.4 Volts
Junction Temp.; -85~302 Degrees F
Mounting Force; 360 in-lb
Stud Size; 3/4-16 UNF-2A
Lead Type; Flexible
Lead Length FMS (inches); 5.44 Inches
RoHS Compliant; Yes ;
R6012030XXYA
Riferimenti Specifici
- MPN
- R6012030XXYA
