71HFR120

10,40 $
Nessuna tassa

IGBT - IPM

Última actualización

Datasheet71HFR120

70A/1200V/1U

No identificado

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • STu00c3u0081NDAR RECOVERY DIODES
  • High surge current capability
  • Designed for a wide range of applications
  • Stud cathode and stud anode version
  • Leaded version available
  • Type up to 1600V VRRM

Aplications

  • Applications
  • Battery charges
  • Converters
  • Power supplies
  • Machine tool controls

Vishay Standard Recovery Diodes, 71HF Series

Vishay

71HFR120

DIODE, DO-5L, 1200V, 70A, REV, STD ; Polarity; Anode Stud (Reverse)

Vrrm (volts); 1200 Volts

IF (rms) Amps; 110 Amps

IF (avg) Amps; 70 Amps

Ifsm Amps; 1250 Amps

I2T@60Hz (A2Sec); 6450

I2T@50Hz (A2Sec); 7100

Vfm (volts); 1.35 Volts

Junction Temp.; -85~356 Degrees F

Mounting Force; 30 lbf-inches

Stud Size; 1/4-28 UNF-2A

Lead Type; Flexible

Lead Length FMS (inches); 4.84 Inches

RoHS Compliant; Yes ;

71HFR120

Riferimenti Specifici

MPN
71HFR120
