FSAM10SH60A
26,25 $
Nessuna tassa
FSAM10SH60A
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- IGBT (Smart Power Module)
- UL Certified No. E209204
- 600V-10A 3-phase IGBT inverter bridge including control Ics for gate driving and protection
- Divided negative dc-link terminals for inverter current sensing applications
- Single-grounded power supply due to built-in HVIC
- Typical switching frequency of 15kHz
- Built-in thermistor for over-temperature monitoring
- Inverter power rating of 0.5kW / 100-253 Vac
- Isolation rating of 2500Vrms/min.
- Very low leakage current due to using ceramic substrate
- Adjustable current protection level by varing series resistor value with sence-IGBTs
Aplications
- Applications
- AC 100V - 253V 3-phase inverter drive for
- small power (0.5kW9 ac motor drives
- Home appliances apllications requiring high switching
- frequency operation like washing machines drive system
FSAM10SH60A
Riferimenti Specifici
- MPN
- FSAM10SH60A
