PM50RSE060
157,50 $
Nessuna tassa
PM50RSE060
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- a) Adopting new 4th generation planar IGBT chip, wich performance is improved by 1um fine rule process
- For example, typical VCE(sat) = 1.7 V
- b) Using new Diode wich is designed to get soft reverse recovery characteristics
- 3 phase 50A, 600V current-sense IGBT for 15kHz switching
- 15A, 600V Current-sense regenerative brake IGBT
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for overcurrent, short-circuit, over-temperature & under-voltage
- Acoustic noise-less 3.7 kW class inverter application
- UL Recognized Yellow Card No. E80276 (n)
- File No. E80271
Aplications
- Applications
- General purpose inverter
- servo drives
- motor controls
PM50RSE060
Riferimenti Specifici
- MPN
- PM50RSE060
