PM150RSE060
210,00 $
Nessuna tassa
PM150RSE060
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- a ) Adopting new 4th generation planar IGBT chip, which
- performance is improved by 1 um fine rule process
- For example, typical VCE(sat)=1.7V
- b ) Using new Diode which is designed to get soft reverse
- recovery characteristics
- 3 o/ 150A, 600V Current-sense IGBT for 15kHz switching
- 50A, 600V Current-sense regenerative brake IGBT
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for over-current, short-circuit , over-temperature & under-voltage
- Acoustic noise-less 11kW class inverter applicatio
Aplications
- Applications
- General purpose inverter
- servo drives
- motor control
PM150RSE060
Riferimenti Specifici
- MPN
- PM150RSE060
