SDI-C403

• 4 phase stepping motor microstepping drive
• Features
• Driver ………..Bipolar chopper PWM
• Chopper frequency ……….. 20 - 40 kHz
• Current per phase……….. 1.5 ARMS (2.5A peak)
• Output voltage …… 40 Vdc max.
• Step angle ……… 1 - 1/2 - 1/4 - 1/8
• Inputs …….. Step, direction, drive enable, current reduction ; (CMOS type with integrated 40 kOhms pull-up resistor)
• Output ......... driver status monitor (+- 2 mA max)
• Package ....... CPP - 25 pins /25W)
• Power supply PWM ....... 24 Vdc (40 Vdc max)
• logic ... 5 Vdc +- 10 %
• Operating temperature ........ - 40 to + 85 C

Marca:

No identificado

Características electricas: 1.5A/40VDC/1U
