SKM75GDL123D

440,52 $
Aucune taxe

MODULO TRANSISTOR DARLINGTON

Última actualización

DatasheetSKM75GDL123D

50A/1200V/6U

No identificado

Quantité
Rupture de stock

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Trench IGBT MODULE
  • MOS input (voltage controlled)
  • N channel, homogeneous Si
  • Low inductance case
  • Very low tail current with low temperature dependence
  • High short circuit capability, self limiting to 6 Icnom
  • Latch-up free
  • Fast & soft inverse CAL diodes
  • Isolated copper baseplate using DCB Direct Copper Bonding Technology
  • Large clearance ( 9 mm ) and creepage distances ( 13 mm )

Aplications

  • Applications
  • Switched mode power suppliesDC servo and robot drives
  • Three phase inverters for AC motor speed control
  • Switching (not for linear use)

Semikron IGBTs

Semikron

SKM75GDL123D

IGBT 75A 1200V 7-PACK ; Type; Six-Pack w/ IGBT Brake

Vces; 1200 Volts DC

Ic; 50 Amps

Vges +/-; 20

Ices Max; 1.2 MilliAmps

Vge(th) Min/Max; 4.5~6.5 Volts

Vce(sat) Max; 3 Volts

Height (mm); 22

Width (mm); 105

Depth (mm); 45

RoHS; Yes ;

SKM75GDL123D

Références spécifiques

MPN
SKM75GDL123D
