SKIM455GD12T4D1
498,75 $
Aucune taxe
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Trench IGBT MODULE
- IGBT 4 = Trenchgate technology
- VCE(sat) with positive temperature coefficient
- High short circuit capability
Aplications
- Applications
- High Reliability AC inverter
- drives
Semikron IGBTs
Semikron
SKIM455GD12T4D1
IGBT ; Type; Six-Pack
Vces; 1200 Volts DC
Ic; 450 Amps
Vges +/-; 20
Ices Max; 0.3 MilliAmps
Vge(th) Min/Max; 5~6.5 Volts
Vce(sat) Max; 2 Volts
Height (mm); 34.5
Width (mm); 184.5
Depth (mm); 106.5 ;
SKIM455GD12T4D1
Références spécifiques
- MPN
- SKIM455GD12T4D1
