- Rupture de stock
PM50CLB060
118,35 $
Aucune taxe
PM50CLB060
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- a) Adopting new 5TH generation IGBT (CSTBT) chip,
- which performance is improved by 1um fine
- rule process.
- For example, typical VCE(sat)=1.5V @ Tj125u00c2u00b0C
- b ) I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error outputs is possible from all each conservation upper and lower arm of IPM
- c) New small package
- 3 phase 50A, 600V Current-sense IGBT type inverter
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for, short circuit, over-temperature
- under-voltage (P-Fo available from upper arm devices)
- Acoustic noise-less 3.7kW class inverter applications
Aplications
- Applications
- General purpose inverter
- servo drives
- motorcontrols
Powerex IPMs, Intellimod L Series
Powerex
PM50CLB060
IPM, SIX-PACK, 600V, 50A ; Ic; 50 Amps
Vces; 600 Volts
Circuit Configuration; Three Phase Inverter ;
PM50CLB060
Références spécifiques
- MPN
- PM50CLB060
