40HF120

9,24 $
Aucune taxe

RECTIFICADORES

Última actualización

Datasheet40HF120

40A/1200V/1U

No identificado

Quantité
Rupture de stock

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Stu00c3u00a1ndar Recovery Diodes
  • High surge current capability
  • Stud cathode and stud anode version
  • Leaded version available
  • Types up to 1600 V VRRM
  • RoHS compliant
  • Designed and qualified for multiple level

Aplications

  • Applications
  • Battery charges
  • Converters
  • Power supplies
  • Machine tool controls
  • Welding

Vishay Standard Recovery Diodes, 40HF Series

Vishay

40HF120

DIODE, DO-5, 1200V, 40A, FWD, STD ; Package Type; DO-203AB (DO-5)

Polarity; Cathode Stud (Forward)

Vrrm (volts); 1200 Volts

IF (rms) Amps; 62 Amps

IF (avg) Amps; 40 Amps

Ifsm Amps; 595 Amps

I2T@60Hz (A2Sec); 1450

I2T@50Hz (A2Sec); 1600

Vfm (volts); 1.3 Volts

Junction Temp.; -85~374 Degrees F

Mounting Force; 30 lbf-inches

Stud Size; 1/4-28 UNF-2A

Lead Type; Lug

Lead Length FMS (inches); 1 Inches

RoHS Compliant; Yes ;

40HF120
