SKT1000/16E

218,30 $
Sin impuestos

MODULOS IGBT

Última actualización

DatasheetSKT1000/16E

1000A/1600V/1U

No identificado

Cantidad
Fuera de stock

  Security policy

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Delivery policy

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Line THYRISTOR
  • Hermetic metal cases with ceramic insulators
  • Capsule package for double sided cooling
  • Shallow design with single sided cooling
  • International stu00c3u00a1ndar cases
  • Off-state and reverse voltages up to 2800 V
  • Amplifying gate

Aplications

  • Applications
  • DC motor control (e. g. for
  • machine tools)
  • Controlled rectifiers (e. g.
  • For battery charging)
  • AC controllers (e. g. for
  • temperature control)
  • Recommended snubber network e. g. for VRMS < 400 V : R = 33 Ohms/32W, C = 1 uF

Semikron Phase Control SCRs, SKT1000 Series

Semikron

SKT1000/16E

SCR, TO-200AD, 1600V, 1000A ; Package Style; TO-200AD

Vrrm (volts); 1600 Volts

Vdrm (volts); 1600 Volts

It (rms) Amps; 2300 Amps

It (avg) Amps; 1000 Amps

Itsm Amps; 19000 Amps

di/dt (A/microseconds); 125

dv/dt (V/microseconds); 1000

I2T@50Hz (A2Sec); 1800000

Vtm (volts); 2 Volts

tq (microseconds); 250 MicroSeconds

Irrm Peak (mA); 100 MilliAmps

Idrm Peak (mA); 100 MilliAmps

Igt (mA); 250 MilliAmps

Vgt (volts); 3 Volts

Puck Size (h x dia.) in.; 1x3

Junction Temp.; 257 Degrees F

Mounting Force; 22~25 kN

RoHS; Yes

Diag. No.; SEKG_SCR_DIAG_B14

SKT1000/16E

Referencias específicas

MPN
SKT1000/16E
