- Fuera de stock
SKIIP11NAB126V1
68,25 $
Sin impuestos
Security policy
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Delivery policy
(Envíos de 1-2 días hábiles para productos de stock)
Features
- 3-Phase Bridge Rectifier +brake chopper + 3-Phase Bridge Inverter MODULE
- Fast Trench IGBTs
- Robust and soft freewheeling diode
- in CAL technology
- Highly reliable spring contacts for
- electrical connections
- UL recognized file no. E63532
Aplications
- Applications
- Inverter up 8 kVA
- Typical motor power 4 kW
Semikron CIM, MiniSKiiP 1 Series
Semikron
SKIIP11NAB126V1
CIM,1200V,16A,3PH BRID,BRK CHOPPER, 3PH INVERTER ; Ic; 16 Amps
Vces; 1200 Volts
Circuit; Three phase rectifier with brake chopper with three phase inverter
Brake; Yes
Temperature Sensor; Yes
Height; 0.62 Inches
Width; 1.65 Inches
Depth; 1.57 Inches
Weight; 1.23 Ounces
Approvals; UL ;
