Features | Aplicaciones |
- Line THYRISTOR
- Features
- Hermetic metal cases with ceramic insulators
- Threaded studs ISO M16 x 1.5 or UNF 3/4 - 16
- International stándar cases
| - Applications
- DC motor control (e. g. for
- machine tools)
- Controlled rectifiers (e. g.
- For battery charging)
- AC controllers (e. g. for
- temperature control)
- Recommended snubber network e. g. for VRMS < 400 V : R = 33 Ohms/13W, C = 0.47 uF
|
Marca: No identificadoCaracterísticas electricas: 160A/1400V/1U |
Semikron Phase Control SCRs, SKT160 Series Type : SCR, M16, 1400V, 160A, M16X1.5 METRI |
---|
Package Style | TO-93 | Vrrm (volts) | 1400 Volts | Vdrm (volts) | 1400 Volts | It (rms) Amps | 280 Amps | It (avg) Amps | 158 Amps | Itsm Amps | 4300 Amps | di/dt (A/microseconds) | 100 | dv/dt (V/microseconds) | 1000 | I2T@50Hz (A2Sec) | 92500 | Vtm (volts) | 1.75 Volts | tq (microseconds) | 120 MicroSeconds | Irrm Peak (mA) | 50 MilliAmps | Idrm Peak (mA) | 50 MilliAmps | Igt (mA) | 200 MilliAmps | Vgt (volts) | 3 Volts | Stud Size | M16 x 1.50 | Lead Length FMS (inches) | 7.48 Inches | Junction Temp. | 266 Degrees F | Mounting Force | 265 lbf-inches | Diag. No. | SEKG_SCR_DIAG_B6 |
|
Contáctanos para mas información sobre este u otros productos ventas@ims-refacciones-industriales.com
|
