ST230S08P0V

155,93 $
steuerfrei

VARIOS

PDF ST230S08P0V

Características Eléctricas: 230A/800V/1U

Marca: No identificado

Menge
Nicht auf Lager

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

FeaturesAplicaciones
  • PHASE CONTROL THYRISTOR
  • Features
  • Center amplifying gate
  • Hermetic metal case with ceramic insulator (also available with glass-metal seal up to 1200V)
  • International estándar case TO-209ab (TO-93)
  • Compression Bonded Encapsulation for heavy duty operations such as severe thermal cycling
  • Applications
  • DC motor controls
  • Controlled DC power supplies
  • AC controllers

Marca:

No identificado

Características electricas: 230A/800V/1U

Vishay Phase Control SCRs, ST Series

Type : SCR,TO-93,800V,230A
Package Style TO-93
Vrrm (volts) 800 Volts
Vdrm (volts) 800 Volts
It (rms) Amps 360 Amps
It (avg) Amps 230 Amps
Itsm Amps 5970 Amps
di/dt (A/microseconds) 1000
dv/dt (V/microseconds) 500
I2T@60Hz (A2Sec) 149000
I2T@50Hz (A2Sec) 163000
Vtm (volts) 1.55 Volts
tq (microseconds) 100 MicroSeconds
Irrm Peak (mA) 30 MilliAmps
Idrm Peak (mA) 30 MilliAmps
Igt (mA) 150 MilliAmps
Vgt (volts) 3 Volts
Stud Size 3/4-16 UNF-2A
Lead Length FMS (inches) 8.03 Inches
Junction Temp. -40~257 Degrees F
Mounting Force 210 lbf-inches
