- Nicht auf Lager
SKT160/16E
77,96 $
steuerfrei
SKT160/16E
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Line THYRISTOR
- Hermetic metal cases with ceramic insulators
- Threaded studs ISO M16 x 1.5 or UNF 3/4 - 16
- International stu00c3u00a1ndar cases
Aplications
- Applications
- DC motor control (e. g. for
- machine tools)
- Controlled rectifiers (e. g.
- For battery charging)
- AC controllers (e. g. for
- temperature control)
- Recommended snubber network e. g. for VRMS < 400 V : R = 33 Ohms/13W, C = 0.47 uF
Semikron Phase Control SCRs, SKT160 Series
Semikron
SKT160/16E
SCR, M16, 1600V, 160A, M16X1.5 METRI ; Package Style; TO-93
Vrrm (volts); 1600 Volts
Vdrm (volts); 1600 Volts
It (rms) Amps; 280 Amps
It (avg) Amps; 158 Amps
Itsm Amps; 4300 Amps
di/dt (A/microseconds); 100
dv/dt (V/microseconds); 1000
I2T@50Hz (A2Sec); 92500
Vtm (volts); 1.75 Volts
tq (microseconds); 120 MicroSeconds
Irrm Peak (mA); 50 MilliAmps
Idrm Peak (mA); 50 MilliAmps
Igt (mA); 200 MilliAmps
Vgt (volts); 3 Volts
Stud Size; M16 x 1.50
Lead Length FMS (inches); 7.48 Inches
Junction Temp.; 266 Degrees F
Mounting Force; 265 lbf-inches
RoHS; Yes
Diag. No.; SEKG_SCR_DIAG_B6
SKT160/16E
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- SKT160/16E
