skr70-16
search
  • skr70-16

SKR70/16

13,86 $
steuerfrei

MODULOS IGBT

Última actualización

DatasheetSKR70/16

70A/1600V/1U

No identificado

Menge
Nicht auf Lager

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Rectifier Diode
  • Reverse voltage up to 1600 V
  • Hermetic metal cases with glass insulators
  • Threaded studs ISO M8(SKN/R 71 also 1/4-
  • 28UNF)
  • SKN : anode to stud
  • SKR : cathode to stud

Aplications

  • Applications
  • All-purpose mean power rectifier
  • diodes
  • Cooling via heatsinks
  • Non-controllable and
  • half-controllable rectifiers
  • Free-wheeling diodes

Semikron Standard Recovery Diodes, SKN70 Series

Semikron

SKR70/16

DIODE, M8LIL, 1600V, 70A, FWD, STD, M8X1.25, 135mm FMS ; Package Type; Case E 12

Polarity; Cathode Stud (Forward)

Vrrm (volts); 1600 Volts

IF (rms) Amps; 150 Amps

IF (avg) Amps; 95 Amps

Ifsm Amps; 1150 Amps

I2T@60Hz (A2Sec); 6600

I2T@50Hz (A2Sec); 6600

Vfm (volts); 1.5 Volts

Junction Temp.; 356 Degrees F

Mounting Force; 35.40 lbf-in

Stud Size; M8 x 1.25

Lead Type; Flexible Insulated Yellow

Lead Length FMS (inches); 5.31 Inches ;

SKR70/16

Besondere Bestellnummern

Hersteller-Teilenummer (MPN)
SKR70/16
