SKM150GAL12T4
73,64 $
steuerfrei
SKM150GAL12T4
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Fast IGBT 4 Module
- IGBT4 = 4. generation fast trench IGBT (Infineon)
- CAL4 = Soft switching 4. generation CAL-diode
- Isolated copper baseplate using DBC technology (Direct Bonded Copper)
- Increased power cycling capability
- With integrated gate resistor
- For Higher switching frequenzies up to 20kHz
- UL recognized, file no. E 63532
Aplications
- Applications
- Electronic welders at fsw up to 20 kHz
- DC/DC - converters
- Brake choppers
- Switched reductance motor
Semikron IGBTs
Semikron
SKM150GAL12T4
IGBT 150A 1200V LOW CHOPPER ; Type; Single
Vces; 1200 Volts DC
Ic; 150 Amps
Vges +/-; 20
Ices Max; 2 MilliAmps
Vge(th) Min/Max; 5~6.5 Volts
Vce(sat) Max; 2.05 Volts
Height (mm); 30.1
Width (mm); 94
Depth (mm); 34
Approvals; UL ;
SKM150GAL12T4
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- SKM150GAL12T4
