Features | Aplicaciones |
- Fast Recovery Diode
- Features
- High power Fast recovery diode eries
- 2.0 us to 3.0 us recovery time
- High voltage ratings to 3000 V
- High current capability
- Optimized turn-on and turn-off characteristics
- Low forward recovery
- Fast and soft reverse recovery
- Press PUK encapsulation
- Case style conform to JEDEC DO-200AC
- Maximun juntion temperature 150 C
| - Applications
- Snubber diode for GTO
- High voltage freewheeling diode
- Fast recovery rectifier
|
Marca: No identificadoCaracterísticas electricas: 1650A/000V/1U |
Vishay Fast Recovery Diodes, SD Series Type : DIODE, DO-200AC, 2500V, 1550A, 2000n VS-SD1553C25S20K |
---|
Package Type | DO-200AC | Puck Size (h x dia.) in. | 1 x 3 inches | Vrrm (volts) | 2500 Volts | IF (rms) Amps | 3100 Amps | IF (avg) Amps | 1825 Amps | Ifsm Amps | 26180 Amps | (A2Sec) | 2854 | (A2Sec) | 3126 | Vfm (volts) | 2.23 Volts | trr (nanoseconds) | 2000 NanoSeconds | Junction Temp. | -40~302 Degrees F | Mounting Force | 22.25 kN |
|
Contáctanos para mas información sobre este u otros productos ventas@ims-refacciones-industriales.com
|
