Features | Aplicaciones |
- General Purpose Rectifier
- Features
- Stándar and Reverse Terminals Available
- Flag Lead and Stud Top Terminals Available
- High Surge Current Ratings
- High Rated Blocking Voltages
- Special Electrical Selection forParallel and Series Operation
- Glazed Ceramic Seal Gives High Voltage Creepage and Strike Paths
- Compression Bonded Encapsulation
- JAN Types Available
| - Applications
- Weldres
- Battery Charges
- Electromechanical Refining
- Metal Reduction
- General Industrial High Current Rectification
|
Marca: No identificadoCaracterísticas electricas: 300A/600V/1U |
Powerex Standard Recovery Diodes, R611 Series Type : DIODE, DO-9, 600V, 300A, REV, STD |
---|
Package Type | DO-205AB (DO-9) | Polarity | Anode Stud (Reverse) | Vrrm (volts) | 600 Volts | IF (rms) Amps | 470 Amps | IF (avg) Amps | 300 Amps | Ifsm Amps | 6500 Amps | I2T@60Hz (A2Sec) | 175000 | Vfm (volts) | 1.4 Volts | Junction Temp. | -85~374 Degrees F | Mounting Force | 360 in-lb | Stud Size | 3/4-16 UNF-2A | Lead Type | Flexible | Lead Length FMS (inches) | 5.48 Inches |
|
Contáctanos para mas información sobre este u otros productos ventas@ims-refacciones-industriales.com
|
