50RIA20

$ 20,79
Sem imposto

SCR - THYRISTOR CONTROL DE FASE SCR - THYRISTOR CONTROL DE FASE

PDF 50RIA20

Características Eléctricas: 50A/200V/1U

Marca: No identificado

Quantidade
Esgotado

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

FeaturesAplicaciones
  • MEDIUM POWER THYRISTOR
  • Features
  • High current rating
  • Excellent dynamic characteristics
  • dv/dt = 1000V/us option
  • Superior surge capabilities
  • Estándar package
  • Metric threads version available
  • Types up to 1600V DRM/ V RRM
  • Applications
  • Phase control in converters
  • Lighting circuits
  • Battery charges
  • Regulated power supplies and temperature
  • and speed control circuit
  • Can be supplied to meet stringent military,
  • aerospace and other high-reliability requirements

Marca:

No identificado

Características electricas: 50A/200V/1U

Vishay Phase Control SCRs, RIA Series

Type : SCR, TO-65, 200V, 50A
Package Style TO-65
Vrrm (volts) 200 Volts
Vdrm (volts) 200 Volts
It (rms) Amps 80 Amps
It (avg) Amps 50 Amps
Itsm Amps 1490 Amps
di/dt (A/microseconds) 200
dv/dt (V/microseconds) 500
I2T@60Hz (A2Sec) 93000
Vtm (volts) 1.6 Volts
tq (microseconds) 110 MicroSeconds
Irrm Peak (mA) 15 MilliAmps
Idrm Peak (mA) 15 MilliAmps
Igt (mA) 250 MilliAmps
Vgt (volts) 3.5 Volts
Stud Size 1/4-28 UNF-2A
Junction Temp. -40~257 Degrees F
Mounting Force 30 lbf-inches
