- Esgotado
SKIM400GD126DM
$ 774,38
Sem imposto
SKIM400GD126DM
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- IGBT Module
- Trench gate IGBT with field stop layer
- Low inductance case
- Fast & soft inverse CAL diodes
- Isolated by AIN DCB (Direct Copper onded)
- ceramic plate
- Pressure contact technology for thermal conracts
- Spring contact system to attach driver PCB to the control terminals
- Integrated temperature sensor
Aplications
- Applications
- Switched mode power supplies
- Three phase inverters for AC
- motor speed control
- Switching (not for linear use)
Semikron IGBTs
Semikron
SKIM400GD126DM
IGBT ; Type; Six-Pack
Vces; 1200 Volts DC
Ic; 300 Amps
Vges +/-; 20
Ices Max; 0.6 MilliAmps
Vge(th) Min/Max; 4.95~6.55 Volts
Vce(sat) Max; 2.15 Volts
Height (mm); 32
Width (mm); 123
Depth (mm); 106.5 ;
SKIM400GD126DM
Referências específicas
- MPN
- SKIM400GD126DM
