PM200RL1A060
$ 874,13
Sem imposto
PM200RL1A060
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- Inverter + Drive & Protection IC
- a) Adopting new 5th generation Full-Gate CSTBT chip The over-temperature protection wich detects the chip surface temperature of CSTBT is adopted c) Error output signal is possible from all each protection upper and lower arm of IPM d) Compatible L-series package 3 phase 200A/600V The Current-senser and the thermal sense and temperature sense IGBT type inverter
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits
- for, short circuit, over temperature & under-volatage (P-Fo available from upper arm devices)
- UL Recognized
Aplications
- Applications
- General purpose inverter
- servo drives
- motor controls
Powerex IPMs, Intellimod L Series
Powerex
PM200RL1A060
IPM,7-PACK,600V,200A,SCREW MTG ; Ic; 200 Amps
Vces; 600 Volts
Circuit Configuration; Three Phase Inverter with Brake ;
PM200RL1A060
Referências específicas
- MPN
- PM200RL1A060
